Building an AI Agent Org Chart

Category:aiTags:aiclaude-codeagentsorchestrationbot-wiki
A working multi-agent setup with named roles, a shared wiki, and an orchestration agent that coordinates between them.

Table of contents

A warning

As of 2026-03-11, this is a "Hey this is neat" post and not a "this works really well!" one. I found the process of building and testing this really fun, but I've also been using this approach for basically no time at all and I'm sure a bunch of the things I'm trying here are just going to straight up not work the way I want in the long run. I'll be iterating on it a lot. The bot-wiki is meant to be kept up to date and that + the code are probably the right places to check (or just ask me) how things are working later on in time.

Why an org chart for AI agents

Because it's cool, mostly. Also I hope it will work really well. But mostly, it's cool.

I've defined a team of Claude Code agents that each have a named role, themed around being a virtual agent company. Any of them work fine on their own:

claude --agent cmo -p "What are my top 5 posts by pageviews?"

The benefit is persistent context. Each agent definition carries its goal, tools, rules, and domain knowledge. I don't re-explain what the CMO does every time I invoke it. The definition is the context.

The challenge is coordination. When a request spans multiple agents, someone has to decide which agents to call, in what order, and how to stitch the results together. That's robot work, not a good use of human time. I also don't want to be the medium for shared context, copying output from one agent into another's prompt.

I repurposed my OpenClaw agent Pai into an orchestrator. Pai decomposes multi-agent requests and invokes the right agents in sequence. The C-suite agents (CMO, CFO, CTO, CDO, CSO) each own a domain and can sub-orchestrate their own subagents. The CMO delegates to SEO, the CFO delegates to Cost Tracker, and so on. The top-level/C-Suite agents also work as antagonistic loop orchestrators of their own, I like to think of it as them enforcing high standards.

The agents

Agent Role Model Key Tools
Pai Orchestration Sonnet Bash, Linear MCP
CMO Traffic and growth Sonnet GA4 Analytics MCP
CFO AI spend Sonnet OpenRouter MCP
CTO Delivery, blockers Sonnet Linear MCP, Bash
CDO Knowledge management Sonnet Wiki read/write, Bash
CSO Security and privacy Sonnet File tools, Bash
AR Agent onboarding, mediation Sonnet File tools, Bash
Publisher Blog content pipeline Sonnet Bash, file tools
SEO Search audits Sonnet GA4, WebSearch
Cost Tracker Spend reports Haiku OpenRouter MCP
Librarian Wiki read/write Haiku Wiki file tools
Privacy Auditor Flag confidential data Haiku File tools
Researcher Gather sourced facts Sonnet WebSearch, Read
Writer Draft posts from briefs Sonnet Read, Write
Fact Checker Verify claims Haiku WebSearch, Read
Reviewer Style and structure Haiku Read, Grep
QA Production readiness Sonnet Bash, Playwright

Each C-suite agent owns a domain and has subagents for specialized work. SEO reports to the CMO. Cost Tracker reports to the CFO. The Librarian reports to the CDO. The Privacy Auditor reports to the CSO. AR (Agent Resources, the HR department) handles agent onboarding and role boundary mediation.

The Publisher is its own sub-org with a four-stage content pipeline: researcher, writer, fact-checker, and reviewer. QA runs after the pipeline to verify the post actually builds, renders, and links correctly before it goes live.

Every agent connects to real MCP servers. No mocks. The CMO queries real GA4 data. The CFO pulls real OpenRouter bills.

The org chart

This is accurate as of 2026-03-12. The bot-wiki org chart stays up to date as agents are added or reorganized.

graph TD
    Kyle["Kyle"]
    Pai["Pai — Executive Assistant"]
    CMO["CMO — Grow Readership"]
    CFO["CFO — Optimize Spend"]
    CTO["CTO — Delivery"]
    CDO["CDO — Knowledge"]
    CSO["CSO — Security"]
    AR["AR — Agent Resources"]
    Publisher["Publisher — Content Pipeline"]

    SEO["SEO Subagent"]
    CostTracker["Cost Tracker"]
    Librarian["Librarian"]
    PrivacyAuditor["Privacy Auditor"]

    Researcher["Researcher"]
    Writer["Writer"]
    FactChecker["Fact Checker"]
    Reviewer["Reviewer"]
    QA["QA"]

    Kyle --> Pai
    Kyle --> CMO
    Kyle --> CFO
    Kyle --> CTO
    Kyle --> CDO
    Kyle --> CSO
    Kyle --> AR
    Kyle --> Publisher

    Pai -.->|orchestrates| CMO
    Pai -.->|orchestrates| CFO
    Pai -.->|orchestrates| CTO
    Pai -.->|orchestrates| CDO
    Pai -.->|orchestrates| CSO
    Pai -.->|orchestrates| AR
    Pai -.->|orchestrates| Publisher

    CMO --> SEO
    CFO --> CostTracker
    CDO --> Librarian
    CSO --> PrivacyAuditor

    CMO -.->|reads/writes| Librarian
    CFO -.->|reads/writes| Librarian
    CTO -.->|reads/writes| Librarian

    Publisher --> Researcher
    Publisher --> Writer
    Publisher --> FactChecker
    Publisher --> Reviewer
    Publisher --> QA

It being my blog and virtual team, I get to sit at the top. Every agent is directly invocable by me, but ideally I don't need to do that often.

Solid lines mean "reports to." Dashed lines from Pai mean "orchestrates." Dashed lines to the Librarian mean "can read/write wiki through."

The Privacy Auditor is the gatekeeper. Any agent writing content that will end up in git or on the internet should check with the Privacy Auditor first. It scans for leaked analytics data, spend numbers, secrets, and anything else that shouldn't be public. This came from a scare where one of my agents with access to mildly confidential data referenced it in content that would have been public. I feel strongly that all agent flows need a privacy step at minimum, and ideally agents should have purposefully curtailed access to sensitive data.

Pai is structured as a peer to the other top-level agents, and orchestrator. I can still run claude --agent cmo whenever I want. Pai is for when a request spans multiple agents and I don't want to do the routing myself.

The Librarian is an experiment in context management and shared state. Any agent can talk to it directly to persist notes, plans, or evidence to the wiki. I already built a RAG system over the wiki. Once the wiki gets big enough that agents can't skim it all, I'll have them query the RAG index instead. For now, the agents just use git and local file storage for wiki access. The CDO owns the wiki strategy, but the Librarian does the actual reading and writing.

Pai: the executive assistant

Agent definitions live in .claude/agents/. Here's Pai's frontmatter:

# .claude/agents/pai.md
name: pai
description: >-
  Pai — Executive assistant that orchestrates
  multi-agent workflows
model: sonnet
tools:
  - Bash
  - Read
  - Glob
  - Grep
  - Write
  - mcp__linear-server__list_issues
  - mcp__linear-server__list_projects

The body of the definition has four key sections.

Agent invocation via Bash

Pai invokes other agents with claude --agent <name> -p "prompt" through the Bash tool. Each call is a fresh session. Agents don't share memory or context with each other.

This is the main tradeoff. Fresh sessions mean no shared state, but Pai bridges the gap by reading output from one agent and passing relevant parts into the next agent's prompt.

The alternatives I considered:

  • Shared memory / message bus. Tools like LangGraph or CrewAI give agents shared state. More powerful, but more moving parts. I wanted something I could debug by reading a bash script.
  • Single mega-agent. One agent definition with all the tools. Simpler, but the context window fills up fast and the agent loses focus. Splitting by role keeps each session lean.
  • MCP-based orchestration. Route through an MCP server that manages agent sessions. Interesting, but overkill for a blog. I'd rather build on claude --agent which already works.
  • Beads. A structured task memory for AI agents, backed by Dolt (version-controlled SQL). I looked into it, but it's more of an alternative to Linear than to the wiki. It solves task tracking and agent handoff, not knowledge management. I like Linear for tasks and markdown files for knowledge.

I went with the dumb approach: Bash calls and text passing. It's easy to understand, easy to debug, and the wiki handles long-term memory. If I outgrow it, I'll upgrade.

Dry-run mode

Add --dry-run to your message and Pai outputs the orchestration plan without executing anything. Which agents, what prompts, what order, how it would synthesize.

Useful for checking that Pai will do what you want before it burns tokens on three agent calls.

Adversarial loops

For requests that need critique or review between agents:

  1. Agent A produces output
  2. Agent B critiques it
  3. Agent A revises based on feedback
  4. Up to 3 rounds or until the reviewer approves

CMO proposes blog topics, CTO reviews technical feasibility, CMO revises. The back-and-forth produces better output than either agent alone.

Logging

Every orchestration run appends a timestamped entry to pai-log-YYYY-MM-DD.md. Agent name, prompt summary, result status, and a one-line synthesis.

The wiki layer

Each agent has a page in the Bot-Wiki that documents its goal, tools, subagents, and example prompts.

agent-team/
├── index.md          # org chart and coordination model
├── pai.md            # orchestration agent
├── cmo.md            # traffic and growth
├── cfo.md            # AI spend
├── cto.md            # delivery and blockers
├── cdo.md            # knowledge management
├── cso.md            # security and privacy
├── publisher.md      # blog pipeline
└── phase-2.md        # future async architecture

The wiki is the shared memory layer.

Every agent session is stateless. The CMO doesn't remember what the CTO said last week. But if the CTO writes its findings to the wiki through the Librarian, the CMO can read them next time it runs. The wiki is how agents share context across sessions.

The Librarian (a Haiku subagent under the CDO) handles all wiki read/write operations. Any agent can invoke it directly with claude --agent librarian -p "..." to persist notes, plans, evidence, or whatever else needs to survive between sessions. The CDO owns the strategy: what gets documented, how pages are structured, when content is stale.

This is cheaper than giving every agent write access to the full file system. The Librarian runs on Haiku, knows the wiki format, and won't accidentally clobber unrelated files.

In time I may have the CFO tweak the models the agents use to manage costs, too.

Pai in action

The dry-run

I asked Pai for a quarterly health check with --dry-run:

claude --agent pai -p "Give me a quarterly health check. \
  How's traffic trending, what am I spending on AI, and \
  are there any blocked issues? --dry-run"

Pai planned three parallel agent calls:

Agent 1, CMO: Pull a quarterly traffic report for kyle.pericak.com. Total sessions and users for the quarter vs prior quarter, top 5 posts by pageviews, traffic channel breakdown.

Agent 2, CFO: Pull OpenRouter AI spend for Q1 2026. Break it down by model and by month. Flag any month-over-month spikes > 20%.

Agent 3, CTO: Review all open Linear issues and flag any that are blocked, stalled (no update in 14+ days), or missing an assignee.

It also laid out the synthesis plan: group results by theme (traffic, spend, delivery), cross-reference findings, and call out any cross-domain issues.

No agents ran. No tokens burned. I could review the plan and adjust before committing.

The real run

Same request without --dry-run. Pai invoked three agents and synthesized everything into one report.

Traffic (from CMO): GA4 only had a week of data. The site is new enough that there's no meaningful baseline yet. Almost entirely direct traffic, organic search barely registering. CMO recommended connecting Search Console and revisiting in 30 days.

AI spend (from CFO): well under budget with no pressure. OpenRouter's API only surfaced account-level totals, no per-model breakdown. CFO noted the biggest future lever is routing non-reasoning tasks to flash-tier models.

Delivery (from CTO): most issues done or in backlog, one in progress (this blog post). No hard blockers, but three dependency chains worth watching:

  1. RSS feed is high priority but hasn't started. Four distribution issues are gated on it.
  2. CMO and CFO baseline runs haven't started. They gate two future blog posts.
  3. This post has an open PR to close.

Pai wrote a log entry automatically:

## 21:30 — Quarterly health check

| Agent | Prompt Summary | Result |
|-------|---------------|--------|
| cmo | 90-day traffic trend | success |
| cfo | 90-day AI spend | success |
| cto | Blocked/stalled issues | success: 3 clusters |

**Synthesis:** Early launch phase, minimal spend,
no hard blockers but three dependency chains.

The adversarial demo

I asked Pai to have the CMO propose blog topics and the CTO review feasibility:

claude --agent pai -p "The CMO wants to propose 3 new \
  blog topics. Have CTO review feasibility."

CMO proposed three posts:

  1. Give Your Agents a Memory - wire agents to read/write wiki context on startup
  2. Agents That Run Themselves - scheduled execution with cron and cost guardrails
  3. Teach Your CTO Agent to Review PRs - GitHub Actions workflow that fires the CTO agent on every PR

CTO reviewed each one:

  • Post 6 (wiki memory): needs groundwork. Wiki is read-only from agents today. A write protocol means git commits from within agent sessions.
  • Post 7 (scheduling): blocked. Phase 2 prerequisites from the wiki aren't met. PER-37 and PER-38 haven't started.
  • Post 8 (PR review): needs groundwork. Most self-contained, but .github/workflows/ doesn't exist yet.

CTO's recommended ship order: complete PER-37 and PER-38 first, then post 6, then post 8, then post 7 last (after the others prove stability).

The interesting thing here is the cross-referencing. The CTO pulled the same PER-37/PER-38 dependency from the health check. It flagged the same blocker from two different angles without being told about the first run.

Watching them work

I got bored waiting for the agents to finish doing their thing so I made them all post status updates to a local file. I tail -f the file and watch them work. It's neat. Eventually I think I might plug them into some chat app or something instead so it looks more like people talking to each other. I think that'd be fun.
